    RAD 240 VOLT SERIES TORQUE TOOLS

    The V-RAD Series is a new generation of electric torque wrench used for the installation or removal of heavy duty fasteners where accuracy, power and safety are required. This series comes without the hassle of air hoses and simply runs when plugged into a 220/240 Volt electric power supply or generator. There are three versions in the range, a manual V-RAD which is controlled by a limited number of torque presets,V-RAD Select controlled by two buttons and a screen with increments of ten and the Digital V-RAD which allows the user to define the exact torque required.

    All options come fully calibrated and certified to +/- 5% with a reaction arm and carry case.

    NEED HELP?

    We can help you find the right tool for your application

    1300 2 TORQUE

    (1300 2 867 783)

    V-RAD TORQUE TOOL SERIES

    Standard Features

    • Quick adjust torque settings
    • Fast and accurate “dial a torque” for maximum versatility and efficiency with 11 fixed settings
    • Equal power in forward and reverse
    • Convenience and cost effective use of same tool for break away and final torque
    • Advanced ultra-durable electric motor design
    • Extreme duty design to reduce maintenance costs and increase reliability
    • A 90 degree gearbox version with extra handle for safe handling
    Digital V-RAD Series - Electric Torque Series - Rad Torque Tools

    DV-RAD TORQUE TOOL SERIES

    Digital V-RAD series torque wrenches are the extreme design innovation with fully programmable preset torque settings with torque range up to 2500 Ft. lbs. Smooth continuous flow of controlled torque with single increment torque settings.

    Standard Features

    • Digital display with colour screen
    • Single increment digital torque settings
    • Multilevel password protection
    • Electronic bolt counter
    • Patented legendary gearbox design
    • “Pass/Fail” function
    Part No. Tool Model Sq Dr Torque Speed Weight Noise Level Dimensions (mm)
    Ft.lbs NM RPM Kg Dba A B C D
    MANUAL V-RAD SERIES
    13497 V-RAD 4 3/4″ 100 – 400 136 – 542 29 4.5 80 431 63 76 215
    12899 V-RAD 10 3/4″ 800 – 1000 1085 – 1356 8 4.9 80 457 64 76 215
    21944 V-RAD 10 90 DEGREE 3/4″ 800 – 1100 1085 – 1491 8 5.1 80 220 63 76 495
    12389 V-RAD 16 1″ 500 – 1600 678 – 2169 6 6.5 80 482 76 76 215
    13501 V-RAD 23 1″ 800 – 2300 1085 – 3118 4 7.1 80 465 76 76 215
    21943 V-RAD 23 90 DEGREE 1″ 800 – 2300 1085 – 3118 4 7.3 80 220 76 76 400
    DV-RAD SERIES
    16120 DV-RAD 1000 3/4″ 400 – 1000 542 – 1356 7.7 5.2 80 322 64 70 220
    16121 DV-RAD 1500 1″ 600 – 1000 814 – 2034 5.8 5.4 80 343 69 70 220
    16122 DV-RAD 2500 1″ 1000 – 2500 1356 – 3390 3.2 6.2 80 380 79 70 220
    Electric Torque Series - Rad Torque Tools A & B
    Electric Torque Series - Rad Torque Tools C & D
    Electric Torque Series - Rad Torque Tools 1
    Electric Torque Series - Rad Torque Tools 2
    Electric Torque Series - Rad Torque Tools 3
    Electric Torque Series - Rad Torque Tools 4
